SET T0004 -
Emergency Department

CASE 1

HISTORY	HISTORY Young patient fell on his outstrected hand. Painful elbow.
QUESTION	QUESTION Normal or abnormal?
RADIOGRAPHS	RADIOGRAPHS
ANSWER	ANSWER VIEW The head of the radius is dislocated anteriorly. The abnormal Radio-Capitellar line confirms this diagnosis. *See : Accident & Emergency Radiology : A Survival Guide (3rd edition) : Pages 101 and 104* The 3rd edition will be published in July 2014.

CASE 2

HISTORY	HISTORY Injured shoulder in a rugby match. Now painful.
QUESTION	QUESTION Is this AP view normal or abnormal?
RADIOGRAPHS	RADIOGRAPHS
ANSWER	ANSWER VIEW ACJ subluxation. Note also that the Coraco-clavicular distance (an eyeballing assessment) appears to exceed 1.3cm. This raises the additional possibility that the coraco-clavicular ligaments have also been ruptured. 1.3cm distance? Significance? *See : Accident & Emergency Radiology : A Survival Guide (3rd edition) : Pages 75 and 86* The 3rd edition will be published in July 2014.

CASE 3

HISTORY	HISTORY Asthmatic. Recent attack. Now short of breath.
QUESTION	QUESTION Is this CXR normal or abnormal?
RADIOGRAPHS	RADIOGRAPHS
ANSWER	ANSWER VIEW Right sided pneumothorax.

CASE 4

HISTORY	HISTORY Gradual increase in shortness of breath over the last week.
QUESTION	QUESTION Explain the appearance on this CXR.
RADIOGRAPHS	RADIOGRAPHS
ANSWER	ANSWER VIEW Classic appearance of collapse of the right upper lobe. The most likely underlying cause will depend in large part on the clinical history (eg smoker?; asthmatic?; other?).
